Fluke-Process Meter

******Discontinued****** Please see replacement part # 787B
PROCESSMETER The Fluke 789 ProcessMeter combines a loop calibrator with a DMM to give process technicians double the power in one tool. Fluke 789 has a display that's twice as large and twice as bright with two levels of backlighting. The 789 loop cal

Features

Current measurement: Range: 0-1A; 0-30 mAResolution: 1 mA; 0.001mAAccuracy: 0.2% + 2 LSD; 0.05% + 2 LSD
Current Sourcing: Range: 0-20 mA or 4-20 mAResolution: 0.05% of span Drive Capability: 500Ω @ 24 Ma
Frequency: to 19,999 kHz, 0.005% + 1 LSD
Voltage: Range: 0-1000V AC or DC Resolution: 0.1 mV to 1.0VAccuracy: 0.1% Rdg +1 LSD (VDC)
Resistance: up to 40 MΩ, 0.2% + 1 LSD
Overvoltage category: IEC 1010-1 CAT III
Single 9V battery (included)

Technical Resources

787-manual.pdf

Accessories

Please add a quantity to the following accessories before clicking the "Add to Quote" or "Add to Cart" to add items to your order/quote.

Fluke-Calibration Module
FLUKE-787CAL120
$0.00

Quantity:

CALIBRATION MODULE, US The Fluke 787CAL calibration module permits users and service facilities to perform automated MET/CAL verifications and calibrations of the Fluke 787. The calibration module provides a 9 VDC supply to the 787. At the same time, it facilitates RS232 communication from the PC running MET/CAL to the 787 over the battery leads of the 787.An installation of MET/CAL calibration software, plus appropriate calibration hardware, must be provided by the user. The Fluke 787CAL calibration module comes with a calibration manual, MET/CAL procedures and an interface module that permits serial communication between a Fluke 787 and a PC.
