Teledyne Hastings CVT-26A
Vacuum Controller
0-1000 mTorr Range

Click image to enlarge
(CVT-26A)
Mfg: Teledyne Hastings®
Price Each: $990.00
Quantity:

Teledyne CVT-26A Vacuum Controller (0-1000 mTorr Range, 2 Relay, 115 VAC); (8' Cable Included (Gauge Tubes Sold Seperately))

THI Vacuum Controllers, CVT series are fully automatic, continuous-reading instruments for unlimited vacuum applications. These controllers operate in the same standard ranges as the VT meters with the addition of double user selectable control limits. The control points are durable 5amp single pole double throw relays which can be configured normally open or normally closed.
Features:
  • Operates Hastings Instruments most popular DV-4, DV-5, and DV-6 Gauge Tubes
  • RANGES
  1. DV-4 (0-20 Torr)
  2. DV-5 (0-100 mTorr)
  3. DV-6 (0-1000 mTorr)
  • Compatible with Calibration Reference Tubes
  • Torr Range (0-1000 mTorr)
  • 115 VAC
  • 0-1 VDC Output (non-linear)
  • Control Set-point Relays (CVT only)
  • Dial face available in Torr, mBar, or Pa
  • Corrosion Resistant
  • More options available, Call PTM for Pricing

Applications:

  • Vacuum Metallurgy
  • Vacuum Furnace
  • Refrigeration (HVAC)
  • Freeze Drying
  • Lamp/Bulb Manufacturer
  • Power/Transformer Maintenance
  • Cryogenic/Vacuum Insulation
